UNION TEE

Fitting
Part No
T1 (OD)
L
H
G1
F
SFUT-4-4-4
1/4" T (6.35)
59
44
14
15.5
Part No
T1 (OD)
L
H
G1
F
SFUT-6-6-6
3/8" T (9.52)
65
50
17
17.5
Part No
T1 (OD)
L
H
G1
F
SFUT-8-8-8
1/2" T (12.7)
73
53
22
20.5
Part No
T1 (OD)
L
H
G1
F
DFUT-4-4-4
1/4" T (6.35)
59
44
14
15.5
Part No
T1 (OD)
L
H
G1
F
DFUT-6-6-6
3/8" T (9.52)
65
50
17
17.5
Part No
T1 (OD)
L
H
G1
F
DFUT-8-8-8
1/2" T (12.7)
73
53
22
20.5
ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE SPECIFIED. DIMENSIONS ARE FOR REFERENCE ONLY. SUBJECT TO CHANGE.
