BFTG SERIES

Material
Forged Brass
Body
1
Part
Material
Forged Brass
Disc
2
Part
Material
Forged Brass
Stem
3
Part
Material
PTFE
Seat
4
Part
Material
Forged Brass
Cap
5
Part
Material
NBR
O Ring
6
Part
Forged Brass Body
Non Rising Stem
Up to 200 CWPSI
Temperature -20 to 180 Fahrenheit
Threads Conforms to ANSI B1.20.1
FORGED BRASS GATE VALVE
Material
Forged Brass
Gasket
7
Part
Material
PTFE
Packing
8
Part
Material
Forged Brass
Nut
9
Part
Material
Cast Iron
Handle
10
Part
Material
Carbon Steel
Hex Nut
11
Part
Size
A
B
C
1/4"
2.05
2.56
1/4" NPT
Size
A
B
C
3/8"
2.05
2.68
3/8" NPT
Size
A
B
C
1/2"
2.05
2.56
1/2" NPT
Size
A
B
C
3/4"
2.05
2.68
3/4" NPT
Size
A
B
C
1"
2.36
3.05
1" NPT
D
0.49
D
0.61
D
0.49
D
0.61
D
0.73
E
0.35
E
0.43
E
0.35
E
0.43
E
0.55
F
1.59
F
1.79
F
1.59
F
1.79
F
1.87
Size
A
B
C
1-1/4"
2.83
4.04
1-1/4" NPT
Size
A
B
C
1-1/2"
2.83
4.30
1-1/2" NPT
Size
A
B
C
2"
3.15
5.26
2" NPT
Size
A
B
C
2-1/2"
3.86
6.03
2-1/2" NPT
D
1.02
D
1.50
D
1.73
D
2.05
E
0.51
E
0.51
E
0.55
E
0.67
F
2.18
F
2.24
F
2.56
F
2.83
Size
A
B
C
3"
4.13
7.11
3" NPT
Size
A
B
C
4"
4.96
8.58
4" NPT
D
2.28
D
2.87
E
0.73
E
0.83
F
3.21
F
3.80
