90 DEGREE BUTTWELD ELBOW

Fitting
Part No
T(OD)
N
L
H
G
F
DF9SOBWE-4-4
1/4" T (6.35)
25
22.5
22.5
14
15.5
BW
1/4" BW
Part No
T(OD)
N
L
H
G
F
DF9OBWE-6-6
3/8" T (9.52)
28.5
24.5
24.5
17
17.5
BW
3/8" BW
Part No
T(OD)
N
L
H
G
F
SF9OBWE-4-4
1/4" T (6.35)
14
25
22.5
14
15.5
BW
1/4" BW
Part No
T(OD)
N
L
H
G
F
SF9OBWE-6-6
3/8" T (9.52)
14
28.5
24.5
17
17.5
BW
3/8" BW
ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE SPECIFIED. DIMENSIONS ARE FOR REFERENCE ONLY, SUBJECT TO CHANGE.
