FEMALE CONNECTOR

Fitting
Part #
T(OD)
N
L
H
G
F
SFFC-4-4
1/4" (6.35)
14
36
29
14
19
P(Thread)
1/4" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-4-6
1/4" (6.35)
14
36
29
14
22
P(Thread)
3/8" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-4-8
1/4" (6.35)
19
41
34
14
27
P(Thread)
1/2" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-6-4
3/8" (9.52)
14
38.5
31
17
19
P(Thread)
1/4" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-6-6
3/8" (9.52)
14
38.5
31
17
22
P(Thread)
3/8" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-6-8
3/8" (9.52)
19
43
36
17
27
P(Thread)
1/2" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-8-4
1/2" (12.7)
14
42
31.5
22
22
P(Thread)
1/4" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-8-6
1/2" (12.7)
14
42
31.5
22
22
P(Thread)
3/8" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-8-8
1/2" (12.7)
19
45.5
36
22
27
P(Thread)
1/2" F NPT
Part #
T(OD)
N
L
H
G
F
DFFC-4-4
1/4" (6.35)
14
36
29
14
19
P(Thread)
1/4" F NPT
Part #
T(OD)
N
L
H
G
F
DFFC-4-6
1/4" (6.35)
14
36
29
14
22
P(Thread)
3/8" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-4-8
1/4" (6.35)
19
41
34
14
27
P(Thread)
1/2" F NPT
Part #
T(OD)
N
L
H
G
F
DFFC-6-4
3/8" (9.52)
14
38.5
31
17
19
P(Thread)
1/4" F NPT
Part #
T(OD)
N
L
H
G
F
DFFC-6-6
3/8" (9.52)
14
38.5
31
17
22
P(Thread)
3/8" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-6-8
3/8" (9.52)
19
43
36
17
27
P(Thread)
1/2" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-8-4
1/2" (12.7)
14
42
31.5
22
22
P(Thread)
1/4" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-8-6
1/2" (12.7)
14
42
31.5
22
22
P(Thread)
3/8" F NPT
Part #
T(OD)
N
L
H
G
F
SFFC-8-8
1/2" (12.7)
19
45.5
36
22
27
P(Thread)
1/2" F NPT
ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE SPECIFIED. DIMENSIONS ARE FOR REFERENCE ONLY, SUBJECT TO CHANGE.
